Name | 1995 Cincinnati Milacron T-35 5 Axis Horizontal Machining Center w/Siemens Acramatic 950 Control |
---|---|
Aucto ID | 10006 |
Manufacturer | CINCINNATI MILACRON |
Model | T-35 |
Year of Manufacture | 1995 |
Additional Info | Condition: Fair
Condition details: APPX SPINDLE RUN 12010 HR
APPX IN CYCLE 27995 HR
ASSESSMENT ON 7/3/23
XY CIRCULARITY 0.0021 TRUE POSITION 0.0043
YZ CIRCULARITY 0.0012 TRUE POSITION 0.0031
ZX CIRCULARITY 0.0015 TRUE POSITION 0.0031
Axis Travel /Ranges .
X Axis (Column) 60"-Range CL of B to CL of Spindel +/- 30"..
Y Axis (Spindle Carrier) 60"-Range Top of pallet to CL of Horizontal Spindel 60".
Z Axis (Table) Range CL of B Axis to Horizontal spindle Gage Line -12.5" to 49.5" .
Range CL of B Axis to CL of Vertical Spindle 0 to 62".
Spindle.
40 hp motor.
Speed 0-4000 RPM.
Draw Bar Clamping Force 9000 lbs. .
Cat 50 taper .
Pallet Work Surface.
31.5" Sq.
Max work piece Dia 50".
Max Work Piece height 50".
Max Weight 4500 lbs.
Linear Axis Feed Rates and Thrust.
Feed Rates X, Y,Z .5-150 ipm..
Rapid Traverse Rates 300 ipm.
Max Continuous Thrust X, Y 3000 lbs. Z 5000 lbs..
A Axis Contouring Spindle Feed Rates.
2_/min to 800_/min.
B-Axis Contouring Table Fed Rates .
5_/min to 550_/min.
Accuracy.
Linear +/- .0004".
Angular +/- 5 arc seconds .
Automatic tool changer.
Storage 65 tools .
Max tool weight 75 lbs.
Max tool length 25".
Max tool dia with full pockets 4" with adjacent pocket empty 12".
Chip Conveyor.
Coolant .
flood coolant and through the spindle (49 gal res ).
Automictic work changer .
The AWC is floor mounted and tied to the front base and is used to move pallets on and off of Z axis .
RFID Tool Management .
Voltage 460 +/- 10%.
Current 112 amps.
KVA 89 .
60 Hz .
Air 10 scfm 90-60 psi. |
