2004 NORTON PRISMA 120 R CAPSULE SPINNER

SERIAL / VIN NUMBER: 200.248 CONDITION: FAIR HIGH BID IS SUBJECT TO CONFIRMATION. THIS ASSET IS ALSO BEING OFFERED AS PART OF ASSET 80215 [COMPLETE BOTTLING LINE A]. SELLER RESERVES THE RIGHT TO SELL THIS ASSET TO THE HIGH BIDDER OF ASSET 80215. SUBJECT TO DELAYED REMOVAL. CONTACT FOR DETAILS __________________________________________________________ TECHNICAL DRAWINGS ARE ATTACHED VOLTS 480 KW 3 HZ 60 AIR CONSUMPTION NL/T AIR PRESSURE MPA 6 WEIGHT 1500 KG SPEED RATING: UP TO 150BPM CAPSULE TYPES: TIN AND POLY LAMINATED ALUMINUM CAPSULE SIZE: 28-32 MM DIAMETER C UP TO 60MM LENGTH BOTTLE HEIGHT 235-360MM BOTTLE DIAMETER: 60-120MM MAIN DRIVE MOTOR:0.75KW SEW EURODRIVE SPEED CONTROLS: ALLEN-BRADLEY POWER FLEX 70 SPINNER HEAD MOTOR: 1.5 KW SEW EURODRIVE ALLEN-BRADLEY POWER FLEX 70 CAPSULE DISPENSER TIMING: OMRON PLC SYSMAC CQM1H-CPU21 OPERATING VOLTAGE: 480 VOLT, 3-PHASE, 60 HZ CONTROL VOLTAGE: 24 VOLT DC AIR PRESSURE: (6-7 BAR 90-100 PSIG) AIR CONSUMPTION: 250 LITERS PER MIN BOTTLE FLOW DIRECTION: LEFT-RIGHT
